| MAX. DISTANCE FROM COULMN SURFACE TO SPINDLE CENTER | 950 mm |
| MIN, DISTANCE FROM COULMN SURFACE TO SPINDLE CENTER | 210mm |
| TRAVEL OF SPINDLE HEAD | 755 mm |
| MAX DISTANCE FROM BASE SURFACE TO SPINDLE END | 1225 mm |
| MIN DISTANCE FROM BASE SURFACE TO SPINDLE END | 385 mm |
| ELEVATING HEIGHT OF ARM | 625 mm |
| EFFECTIVE AREA OF BOX TABLE | 600 x 445 x 380 |
| STORKE OF SPINDLE | 210 |
