| MAX. DISTANCE FROM COULMN SURFACE TO SPINDLE CENTER | 1275mm |
| MIN, DISTANCE FROM COULMN SURFACE TO SPINDLE CENTER | 305 mm |
| TRAVEL OF SPINDLE HEAD | 970 mm |
| MAX DISTANCE FROM BASE SURFACE TO SPINDLE END | 1330 mm |
| MIN DISTANCE FROM BASE SURFACE TO SPINDLE END | 438 mm |
| ELEVATING HEIGHT OF ARM | 625 mm |
| EFFECTIVE AREA OF BOX TABLE | 635 × 520 × 420 |
| STORKE OF SPINDLE | 210 |
